Name: 8 Channel Relay Module -12V
SKU: A145328
Availability: InStock

8 Channel Relay Module -12V

₹312.00 (Including GST)

8 Channel Relay Board 12V – This 8 Channel 12V Relay Module with Optocoupler meets the safety standard as control areas and load areas have the isolation groove. Optical coupling isolation module. The triggering of the 8-Channel Relay Module is reliable and more stable. The double FR4 circuit board design is a high-end SMT process. It has power and relay operation instructions. Relays terminals (C, NC, NO) are accessible through screw terminals which makes wiring up the board very easy. The inputs of the 8 Channel 12V Relay Module are isolated to protect any delicate control circuitry. A wide range of microcontrollers such as Arduino, AVR, PIC, ARM, and so on can control it. The use of such a high-voltage relay eliminates the risk of heating up of the relay as electromechanical relays limit the current consumption in accordance with a voltage rating.

Features: 8 Channel relay Board

Using high-current relay, AC250V 10A DC30V 10A.
Contact some independent wiring, safe and reliable.
The standard interface can be extended to a variety of development boards.
With fixed screw holes for easy installation.
Suitable for a variety of platforms such as 8051/AVR/AVR/ARM.

35 People watching this product now!

SKU: A145328 Category: Relay Boards

Description

8-Channel Relay Board 12V – This is a 12V 8-Channel Relay interface board, Be able to control various appliances and other equipment with a large current. It can be controlled directly by a Microcontroller (Arduino, 8051, AVR, PIC, DSP, ARM, MSP430, TTL logic).

Unleash the true power of your Arduino projects with the versatile 8-Channel Relay Board 12V. This innovative board acts as a bridge between your Arduino and various electronic devices, providing you with the ability to control up to eight different devices simultaneously. Whether you’re working on home automation, robotics, or industrial applications, this relay board is a must-have tool in your arsenal. Equipped with advanced features such as opto-isolation, the 8-Channel Relay Board 12V ensures safe and reliable operation, protecting your Arduino from any potential harm. Its compatibility with a wide range of Arduino models makes it a convenient choice for both beginners and experienced makers. With its compact size and easy installation, this relay board offers unparalleled convenience. Whether you want to control lights, motors, or other electronic devices, this board provides the flexibility and reliability you need. Unlock the full potential of your Arduino projects with the 8-Channel Relay Board 12V. Get ready to take your creations to the next level and bring your ideas to life.

This 8 Channel 12V Relay Module with Optocoupler meets the safety standard as the control areas and load area has the isolation groove. Optical coupling isolation module. The triggering of the 8-Channel Relay Module is reliable and more stable. The double FR4 circuit board design is a high-end SMT process. It has power and relay operation instructions. Relays terminals (C, NC, NO) are accessible through screw terminals which makes wiring up the board very easy. The inputs of the 8 Channel 12V Relay Module are isolated to protect any delicate control circuitry. A wide range of microcontrollers such as Arduino, AVR, PIC, ARM, and so on can control it. The use of such a high-voltage relay eliminates the risk of heating up of the relay as electromechanical relays limit the current consumption in accordance with a voltage rating.

Meaning of High-level and Low-level

High-level trigger refers to using the anode voltage at the VCC connection way of a trigger and triggers the end when the trigger side has the positive voltage or to trigger voltage when the relay is off.
Low-level trigger refers to using the negative voltage at the GND connection way of a trigger and triggers the end when the trigger side has 0 v low voltage or voltage to can trigger, the relay is off.

Specifications:- 8 Channel Relay Board 12V

Channel – 8
Operating Voltage (VDC) – 12
Trigger Voltage (VDC) – 12
Switching Voltage (VAC) – 250@10A
Switching Voltage (VDC) – 30@10A
PCB hole diameter (mm) – 3.1
PCB hole pitch distance (mm) – 132 mm (x-pitch), 50.5 mm (y-pitch)
Length (mm) – 138
Width (mm) – 57
Height (mm) – 17
Weight (gm) – 110

Features: 8 Channel Relay Board 12V

Equipped with high-current relay 10A@250VAC / 10A@30VDC
It can control both AC and DC appliances such as Solenoids, Motors, lights, fans, etc.
High-quality screw terminals (Terminal Block) provided (C, NC, NO) for quick and easy connection
Freewheeling diode to protect your microcontroller
Input Signal Pin connected to Burg stick for easy accessibility
LED Status indicators to indicate the relay ON/OFF status
Mounting holes provided
Signal input with a high-level signal, the common and often start conduction;
The relay can directly control all kinds of equipment and loads;
One often opened a normally closed contact;
Blue KF301 terminal line is more convenient.
It is also able to control various appliances and other types of equipment with a large current.
Red working status indicator lights are conducive to safe use. Widely used for all MCU control, industrial sector, PLC control, and smart home control.
