    USB to UART/RS232 Converter – CP2102

    Original price was: ₹600.00.Current price is: ₹306.00. (Including GST)

    Installs virtual Serial COM Port on your PC through USB so any software can connect to your end device having UART/RS232 port. The UART port is exposed via a  4 pin 0.1″ standard vertical header, and the RS232 port is exposed via a DB9 Male connector just like what you can find on the back of old PC’s motherboards. Note that the UART port uses 3.3V logic.

    Out of stock

    ENQUIRY!
    51 People watching this product now!
    Category:
    Description

    Description

    Features and Specifications

    • USB Specification 2.0 compliant; full-speed (12 Mbps)
    • Supports Windows 8/7/Vista/Server 2003/XP/2000, Mac OS-X/OS-9, Linux
    • Standard RS232 interface
    • Bidirectional UART serial data transfer at various baud rates
    • Easy to use, Works out of the box without any configuration
    • Power LED indication
    • Output header is standard DB9 Male
    • UART Header, 4 pin, 3.3V logic
    • USB Type B Connector



    Resources

    1. CP2102 Virtual Com Port Drivers
    2. CP2102 datasheet
    3. CP2102 Product page
