Description

Ai-WB2-12F CP2102 Board

The ADIY Ai-WB2-12F Board is a Wi-Fi and Bluetooth module developed by ADIY in India, utilizing the Ai-WB2-12F module from Shenzhen Ai Thinker Technology Co., Ltd. This versatile module features the BL602 chip as its core processor, supporting Wi-Fi 802.11b/g/n and BLE 5.0 protocols.

Connectivity:

• Wi-Fi Protocol: 802.11b/g/n.
• Bluetooth Protocol: BLE 5.0.

Key Features:Ai-WB2-12F Board(CP2102)

• Core Processor: BL602 chip with a built-in 32-bit RISC CPU.
• Memory: 276KB RAM.
• Power Consumption: Designed for low power consumption.
• Peripheral Interfaces: Includes SDIO, SPI, UART, VDC, IR remote, PWM, ADC, DAC, PIR, and GPIO.
• DIP 30 Package
• Wi-Fi Protocol: Supports IEEE 802.11 b/g/n with security protocols including WPS, WEP, WPA, WPA2 Personal, WPA2 Enterprise, and WPA3.
• Bandwidth and Speed: Supports 20MHz bandwidth with a maximum speed of 72.2 Mbps.
• Bluetooth: BLE 5.0 and Bluetooth Mesh support.
• Operating Modes: Station + BLE mode, Station + Soft AP + BLE mode.
• Processor and Memory: 32-bit RISC CPU with 276KB RAM.
• Security Features: Secure startup with ECC 256 signatures, real-time AES decryption (OTFAD) in QSPI and SPI Flash, AES 128 CTR mode, and AES 128, 192, and 256-bit encryption engines. Supports SHA 1/224/256 and TRNG.
• Peripheral Interfaces: SDIO, SPI, UART, VDC, IR remote, PWM, ADC, DAC, PIR, and GPIO.
• Integration: Integrated Wi-Fi MAC/BB/RF/PA/LNA/Bluetooth.
• Power Management: Multiple sleep modes with a deep sleep current of 12μA.
• Development Support: Quick start with universal AT commands and support secondary development with integrated Windows and Linux environments.

Specifications:Ai-WB2-12F Board(CP2102)

• Model: ADIY Ai-WB2-12F Kit
• Package: DIP 30
• Size: 49.66*25.40 (±0.2) mm
• Antenna: On-board PCB antenna
• Frequency: 2400 ~ 2483.5 MHz
• Operating Temperature: -40℃ ~ 85℃
• Storage Environment: -40℃ ~ 125℃, < 90% RH
• Power Supply: Supports 3.3V or 5V, current ≥500mA
• Interfaces: UART/GPIO/ADC/PWM/I2C/SPI I/O
• UART Rate: Default value: 115200 bps
• Bluetooth: BLE 5.0
• Security: WPS/WEP/WPA/WPA2 Personal/WPA2 Enterprise/WPA3
• Flash: Default: 4MByte

Applications:Ai-WB2-12F Board(CP2102)

• Internet of Things (IoT)
• Mobile Devices
• Wearable Electronic Devices
• Smart Homes

This board is ideal for various applications including IoT, mobile devices, wearable electronics, and smart home solutions. Its robust connectivity options and versatile features make it a powerful choice for developers and innovators.

The ADIY Ai-WB2-12F Board is ideal for integrating advanced connectivity and processing capabilities into various applications, making it a powerful choice for innovative IoT solutions.
