Description

RP2040 Pico Board Type C – ADIY FLY, engineered with advanced features tailored for professional users. Powered by the RP2040 microcontroller, this board boasts a generous on-chip memory, a symmetrical dual-core processor complex, a deterministic bus fabric, and a versatile peripheral set complemented by a unique Programmable I/O (PIO) subsystem.

Our RP2040 Type C board is equipped with 4MB of Flash memory and a power supply chip compatible with input voltages ranging from 3.3V to 5.5V, ensuring robust performance across various applications. With 27 GPIO pins, including 4 analog inputs, accessible through 2.54mm-pitch through-hole pads, this board offers unparalleled flexibility for your projects.

Featuring a convenient RESET button, the ADIY FLY RP2040 Type C board simplifies module usage, while an onboard LED provides a clear indication of power supply status. Manufactured on a cutting-edge 40nm process node, the RP2040 delivers exceptional performance, minimal dynamic power consumption, and low leakage, complemented by multiple low-power modes to support extended operation on battery power. Experience the power and versatility of the RP2040 Type C Pico Board with ADIY FLY.

ADIY Fly ype C has been designed to be a low-cost yet flexible development platform for RP2040, with the following key features:

• Pin to Pin as Compatible as Raspberry Pi Pico

• Type C connector

• With RESET Button

• With 4MB FLASH memory

• Dual-core Arm Cortex-M0+ processor, flexible clock running up to 133 MHz

• 264KB on-chip SRAM

• DMA controller

• Accelerated integer and floating-point libraries on-chip

• Drag-and-drop programming using mass storage over USB

• 2 on-chip PLLs to generate USB and core clocks

• 27 GPIO pins, 4 of which can be used as analog inputs

• 2 × UART, 2 × SPI controllers, 2 × I2C controllers, 16 × PWM channels

• 1 × USB 1.1 controller and PHY, with host and device support

• Accurate on-chip clock, Temperature sensor

• 8 × Programmable I/O (PIO) state machines for custom peripheral support

• High quality, low cost, high availability

• Simple yet highly flexible power supply architecture

• Various options for easily powering the unit from micro-USB, external supplies or batteries

• Comprehensive SDK, software examples, and documentation

For full details of the RP2040 microcontroller please see the RP2040 Datasheet.

Specifications: RP2040 Pico Board Type C– ADIY FLY

• USB Connector: Type C

• Form factor:  21 mm × 51 mm

• CPU: Dual-core Arm Cortex-M0+ @ 133MHz

• Memory: 264KB on-chip SRAM; 4MB on-board Flash

• Interfacing: 27 GPIO pins, including 4 analog inputs

• Peripherals:  2 × UART.
                                 2 × SPI controllers.
                                 2 × I2C controllers .
                                16 × PWM channels.
                                  1 × USB 1.1 controller and PHY, with host and Device support.
                                 8 × PIO state machines.

• Input power: 3.3–5.5V DC.

• Reset button: Included

Resources: RP2040 Pico Board Type C– ADIY FLY

• Raspberry Pi RP2040 datasheet – rp2040 datasheet

• Raspberry Pi Pico datasheet
• Hardware design with RP2040
• Getting started with Raspberry Pi Pico: C/C++ development
• Raspberry Pi Pico C/C++ SDK
• Raspberry Pi Pico Python SDK
• Pico RP2040 Arduino Core

For additional information visit: https://www.raspberrypi.com/products/raspberry-pi-pico/

Package Includes: 1 x ADIY FLY (RP2040 Type C Pico Board – ADIY FLY)

• Warranty : 3 months
