Description
PC817 2-channel Optocoupler Isolation module by ADIY
Onboard with 4-Channel PC817 are independent, so they can achieve different voltage control at the same time. Using 4-way PC817 optocoupler, to achieve the control signal and the control signal isolation, you can directly use the microcontroller or other devices IO port to achieve the voltage isolation control, you can achieve a small voltage control, the control side can be an external transistor MOS tube or different voltage levels of the device interface.
Features: PC817 2-Channel Optocoupler Isolation Module
- Driving Port Signal Voltage: 3.6-24V
- Output Port Voltage Port: 3.6-30V
- Output can be switched from Pull-Up or Pull-Down with Jumpers.
Specifications: PC817 2-Channel Optocoupler Isolation Module
- No of Channels: 2
- Input Voltage (V): 3.6-24DC
- Output Voltage (V): 3.6-30DC
- Length (mm): 38
- Width (mm): 29
- Height (mm): 12
- Weight (gm): 5
Applications: PC817 2-Channel Optocoupler Isolation Module
- I/O isolation for MCUs (Micro Controller Units)
- Noise Suppression in Switching Circuits
- Signal Transmission Between Circuits of Different Potentials and Impedances
Package Includes : 1 x PC817 2 Channel Optocoupler Isolation Module
